Building Management System

With a BMS (Building Management System) network, it is possible to retain all the benefits of decentralised ventilation whilst taking advantage of the administrative benefits of centralised control.

Building Management System

Digital BMS monitors all individual systems

Digital BMS monitors all individual systems

Airmasters’ ventilation systems are easy to integrate with the rest of the building automation system. With the BMS system, it is easy to gain a complete overview of operations and programme the systems according to the room’s use.

The units can also run fully automatically, but can be monitored using a BMS network. Airmaster motion sensor and CO2 sensorer can be connected, for data from the units and sensors can be transferred to the BMS network. This reduces installation, operation and maintenance costs.

This reduces installation, operating and maintenance costs. Once the control system is connected to the BMS, all individual ventilation systems are controlled and/or monitored by the BMS.

Airlinq® BMS

Network control can be carried out using Airlinq® BMS, where up to 20 systems are operated via a single Airlinq® Orbit control panel.

Flexibility is the order of the day for the Airlinq BMS system. Up to 20 different air handling units can be controlled by the system from a single control panel. The units can be different types and fitted with different options.

Cooling modules can also be attached to individual units as and when required. Such a degree of flexibility means that units with different levels of performance and options can be connected to a single system, whilst meeting the requirements of any individual room.

Dividing the system into groups of one or more units with a common control system optimises use of their size and sensors.

Control using a single sensor (e.g. CO2 sensor) or a combination (e.g. a motion sensor and a CO2sensor) is also possible. Using sensors overrides the basic operating parameters for individual units, whole groups or all units.

Individual operation, monitoring and programming - plus programming of common parameters - are performed from a single control panel. Connection to an analogue building network (BMS system) is of course also possible.

Benefits

Benefits

  • Airmasters sensorer kan med fordel anvendes og dermed sænke forbrugsomkostningerne.

  • Anlæg med identiske indstillinger og samme styringsbehov ved hjælp af sensorer samles i grupper - dette øger fleksibiliteten og sænker omkostningerne.

  • Forskellige anlæg med forskellige indstillinger og sensorer er muligt. Dette giver maksimal fleksibilitet og mulighed for optimering i.f.t. lokale betingelser og lokalets anvendelse.
    Lokal betjening er muligt med Airlinq Viva betjeningspanel.

    Airmaster sensors can be used, thus reducing installation costs.

  • Units with identical settings and the same control requirements can be grouped using sensors to increase flexibility and reduce costs.

  • Different units with different settings and sensors are possible, giving maximum flexibility and optimising according to local conditions and room use. Local control is possible with Airlinq Viva control panel.

Airlinq® Orbit control panel

Contact us if you want to know more about decentralized ventilation

Our competent sales team is ready to answer your questions and advise you on everything from dimensioning, configuration, installation, and planning - so you can find just the right unit for your needs.
